Arcadia’s latest update brings powerful enhancements designed to simplify schematic editing and speed up daily workflows. Here is a quick look at what is new:
Creating inline connector symbols just got easier.
With the new Property Manager, set the number of pins, choose symbol type, and select a part number – the symbol is generated instantly. You can also double-click to edit properties like reference code and functional description after placement.
💡 Benefit: Cuts down symbol creation steps from 12+ to a few clicks. Ideal for faster design iterations.
Say goodbye to moving wire bends one by one!
Now you can select and move multiple bends together while keeping their alignment and connectivity intact. This saves time and reduces the effort needed for complex layout adjustments.
💡 Benefit: Faster wire path edits, better layout control, and improved design accuracy.
You can now edit component details directly from the datasheet view in the harness drawing. Just click the edit icon to jump to the component’s general page – no need to manually search in the component database.
💡 Benefit: Reduces clicks, preserves context, and improves your design-to-edit cycle.
