Arcadia Release Notes – August 22nd, 2025

Category: New Features, Bug Fixes & Stability Improvements

This release brings enhanced platform stability and improvements that elevate your experience across schematic, harness, and formboard workflows.

Improvements

Auto Snap All in Formboard

A new option to automatically snap bundles to the major grid in Formboard. This removes bends and neatly aligns bundle segments, reducing manual effort and giving you a cleaner, more professional layout in just one click.

Quick Wire Routing

Wire routing has been made more convenient. After concluding the source and destination pins, you can now press the space bar to finalize the wire instead of clicking the tick button in the property manager, streamlining the process while keeping the same workflow.

Strip Length

Harness DSI now includes strip length information. This provides more data for users who utilize the DSI files in scripts or automated workflows for manufacturing.

Fixes and Stability Improvements

Clearer Table Display: Part numbers now remain perfectly aligned within the connector and splice cavity tables, even when header and data stroke values are adjusted.
Reliable Session Handling: Sessions now remain active as expected, preventing unexpected “session expired” interruptions.
Accurate Parts Store Data: Parts Store information is now displayed with improved consistency, so users always see the correct details for their account.
Smoother Virtual Node Deletion: Virtual nodes placed with tape can now be deleted instantly without delays or errors.
Pin Function Labels: Pin function names now stay in their correct positions, even after resizing or rotating custom parts.

Thank you for your continued support and feedback. We are committed to delivering a more stable and efficient Arcadia experience with every release.
